TQC sheen – Viscosity Cup ASTM D1084 D4212 Immersion Zahn
The TQC Viscosity Cup ASTM D1084 D4212 Immersion Zahn is a range of stainless steel (SS303) viscosity cups with fixed stainless steel inner cavity nozzle and handle. Ideal for measuring coatings and other fluids during application or production.
Features:
- Each cup has a long handle to allow the cup to be dipped by hand into a liquid container, which makes it easy to quickly check and adjust the viscosity of many different type of liquids.
- The design of the cup and orifice eliminate hard to clean recesses.
- TQC viscosity cups are made under the continuing quality control procedures.
- Each cup is provided with an engraved unique serial number.
Specifications:
| Cup | Stainless steel, 44.0 cm³ |
| Nozzle | Stainless steel, fixed |
| Handle | Stainless steel |
| Complies with | ASTM D 1084, ASTM D 4212 |
| Weight | 135 – 137 g * |
| Cup width | 36mm |
| Cup height | 62.5mm |
| Max width | 50mm |
| Total height | 330mm |
*(depending on orifice)
ORDERING INFORMATION
Art. No. VF2226
TQC Viscosity Cup ASTM D1084 D4212 Immersion Zahn
Type: made of stainless steel, with fixed stainless steel nozzle, orifice No. 1
Optional: possible to certify by calibration with certified oils
Art. No. VF2227
TQC Viscosity Cup ASTM D1084 D4212 Immersion Zahn
Type: made of stainless steel, with fixed stainless steel nozzle, orifice No. 2
Optional: possible to certify by calibration with certified oils
Art. No. VF2228
TQC Viscosity Cup ASTM D1084 D4212 Immersion Zahn
Type: made of stainless steel, with fixed stainless steel nozzle, orifice No. 3
Optional: possible to certify by calibration with certified oils
Art. No. VF2229
TQC Viscosity Cup ASTM D1084 D4212 Immersion Zahn
Type: made of stainless steel, with fixed stainless steel nozzle, orifice No. 4
Optional: possible to certify by calibration with certified oils
Art. No. VF2230
TQC Viscosity Cup ASTM D1084 D4212 Immersion Zahn
Type: made of stainless steel, with fixed stainless steel nozzle, orifice No. 5
Optional: possible to certify by calibration with certified oils
