TQC sheen – Bird-type Film Applicators, 4 Sided
TQC Bird-type film applicator with flat edges. Four application sides for applying 4 different pre-defined thicknesses. The TQC Bird-type applicator is available in film width 50, 75 and 100mm and suitable for applying a host of different products onto flat and relatively solid substrates. The high-grade stainless steel will not be affected by acid or base elements.
We can give no guarantee of the wet thickness that will be obtained. The wet thickness is dependent upon the solids and vehicle content of the wet material as well as other factors. Film thickness deposited may vary from 40% to 80% of the actual gate clearance of the TQC Bird-type applicator.
Specification:
| Material | DAIDO 440C medical grade Martensitic stainless tool steel. Sub Zero Vacuum hardened (+1756°C to -70°C), hardness HRC 55 (through hardened*) & tempered |
| Surface treatment | Polished |
| Overall accuracy | + 2 μm |
| Accuracy | Better than 3 micron |
| Outer dimensions | 90 * 22 * 22mm / 100 * 22 * 22mm / 115 * 22 * 22mm / 120 * 22 * 22mm / 140 * 22 * 22mm |
*Through hardening versus Case-hardening or surface hardening. Through-hardening means the metal uniformly is hardened throughout the piece. Case- or surface (face / frame) hardening only hardens the top layer of the metal. Once the top layer is degraded excessive wear and tear will occur on the product limiting its life time and affecting accuracy
ORDERING INFORMATION
Art. No. VF2161
TQC Bird-type applicator 50mm, 50/100/150/200µm
Art. No. VF2162
TQC Bird-type applicator 75mm, 50/100/150/200µm
Art. No. VF2163
TQC Bird-type applicator 100mm, 50/100/150/200µm
Art. No. VF2164
TQC Bird-type filmapplicator 60mm, gaps as desired
Max. gap size: 3000µm
Art. No. VF1837
TQC Bird-type film applicator, width 50mm, 4 gaps as desired
Max. gap size: 3000µm
Art. No. VF1530
TQC Bird-type film applicator, width 75mm, 4 gaps as desired
Max. gap size: 3000µm
Art. No. VF1535
TQC Bird-type film applicator, width 100mm, 4 gaps as desired
Max. gap size 3000µm
Art. No. VF1536
TQC Bird-type film applicator, width 80mm, 4 gaps as desired
Max. gap size 3000µm
Art. No. VF1580
TQC Bird-type filmapplicator width 150mm, gaps as desired
Max. gap size: 3000µm
Art. No. VF1581
TQC Bird-type filmapplicator width150mm, 50/100/150/200µm
