TQC sheen – Bird-type Film Applicator, Single Gap
TQC Bird-type film applicator with one flat edge. One application side for applying 1 pre-defined thickness. The TQC Bird-type applicator single gap is available in film width 50 and 75 mm and suitable for applying a host of different products onto flat and relatively solid substrates. The high-grade stainless steel will not be affected by acid or base elements.
We can not give guarantee of the wet thickness that will be obtained. The wet thickness is dependent upon the solids and vehicle content of the wet material as well as other factors. Film thickness deposited may vary from 40% to 80% of the actual gate clearance of the TQC Bird-type film applicator.
Specification:
| Material | DAIDO 440C medical grade Martensitic stainless tool steel. Sub Zero Vacuum hardened (+1756°C to -70°C), hardness HRC 55 (through hardened*) & tempered |
| Surface treatment | Polished |
| Overall accuracy | + 2 μm |
| Accuracy | Better than 3 micron |
| Outer dimensions | 80 * 25 * 15mm (50mm series) / 105 * 25 * 15mm (75mm series) |
*Through hardening versus Case-hardening or surface hardening. Through-hardening means the metal uniformly is hardened throughout the piece. Case- or surface (face / frame) hardening only hardens the top layer of the metal. Once the top layer is degraded excessive wear and tear will occur on the product limiting its life time and affecting accuracy.
ORDERING INFORMATION
Art. No. VF1540
TQC Bird-type film applicator 50mm, one single gap as desired
Art. No. VF1541
TQC Bird-type film applicator 50mm, 50µm
Art. No. VF1542
TQC Bird-type film applicator 50mm, 75µm
Art. No. VF1543
TQC Bird-type film applicator 50mm, 100µm
Art. No. VF1544
TQC Bird-type film applicator 50mm, 125µm
Art. No. VF1545
TQC Prism film applicator 50mm, 150µm
Art. No. VF1546
TQC Bird-type film applicator 50mm, 200µm
Art. No. VF1570
TQC Bird-type film applicator 75mm, one single gap as desired
Art. No. VF1571
TQC Bird-type film applicator 75mm, 50µm
Art. No. VF1572
TQC Bird-type film applicator 75mm, 75µm
Art. No. VF1573
TQC Bird-type film applicator 75mm, 100µm
Art. No. VF1574
TQC Bird-type film applicator 75mm, 125µm
Art. No. VF1575
TQC Bird-type film applicator 75mm, 150µm
Art. No. VF1576
TQC Bird-type film applicator 75mm, 200µm
