TQC sheen – 4-Sided Film Applicators
The TQC 4-Sided Film Applicator (Quadruplex) has four application sides for applying paint films with four different predefined thicknesses, in film width 60 or 80 mm. One side of the applicator is supplied with a guidance support for straight application. This support may be removed as well. The high grade stainless steel will not be affected by acid or base elements.
Specification:
| MATERIAL | ASAB Stavax ESR medical grade stainless tool steel, Sub Zero Vacuum hardened (+1756°C to -70°C), hardness HRC 55 (through hardened) |
| SURFACE TREATMENT | Polished |
| ACCURACY | +/- 2 µm |
ORDERING INFORMATION
Art. No. VF2167
TQC Film Applicator (Quadruplex) width 60mm, four gaps, size on request.
Max. gap size: 3000µm
Art. No. VF2168
TQC Film Applicator (Quadruplex) width 60mm, gaps 15, 30, 60 and 90 µm.
Art. No. VF2169
TQC Film Applicator (Quadruplex) width 60mm, gaps 30, 60, 90 and 120 µm.
Art. No. VF2170
TQC Film Applicator (Quadruplex) width 60mm, gaps 50, 100, 150 and 200 µm.
Art. No. VF2172
TQC Film Applicator (Quadruplex) width 80mm, four gaps, size on request.
Max. gap size: 3000µm
Art. No. VF2173
TQC Film Applicator (Quadruplex) width 80mm, gaps 15, 30, 60 and 90 µm.
Art. No. VF2174
TQC Film Applicator (Quadruplex) width 80mm, gaps 30, 60, 90 and 120 µm.
Art. No. VF2175
TQC Film Applicator (Quadruplex) width 80mm, gaps 50, 100, 150 and 200 µm.
