TES AC/DC mA Clamp Meter PROVA-15
PROVA-15
AC/DC mA Current Probe
Product Features
-
Accurate DC/AC current probe for current measurement.
-
1mDCA high resolution on 4A DC range.
-
0.1mACA high resolution on 400mA AC range
-
One touch zero for DCA adjustment.
-
23 mm diameter jaw.
-
Connect to an oscilloscope to observe current waveform.
-
Connect to a chart recorder/ datalogger/ DMM to record current data..
Description
Electrical Specifications: (23℃±5℃)
AC / DC Current:
| Range | Output | Accuracy | ||
| DC 4A | DC 100mV/A | ±2.0%±3mA | ||
| DC 30A | DC 10mV/A | ±2.0%±30mA | ||
| 50/60Hz | 40-100Hz | |||
| AC 400mA | AC 1mV/A | ±2.0%±0.5mA | ±2.5%±0.5mA | |
| 50/60Hz | 40-400Hz | |||
| AC 4A
(0-400mA) |
AC 100mV/A | ±2.5%±8mA | ±3.0%±8mA | |
| AC 4A
(400mA-4A) |
AC 100mV/A | ±2.5%±3mA | ±3.0%±6mA | |
| AC 30A | AC 10mV/A | ±2.0%±30mA | ±2.5%±30mA | |
| Range | Sensitivity |
| DCA 4A | 0.1mV/1mA DC |
| DCA 40A | 0.1mV/10mA DC |
| ACA 400mA | 0.1mV/0.1mA AC |
| ACA 4A | 0.1mV/1mA AC |
| ACA 40A | 0.1mV/10mA AC |
General Specifications:
| Conductor Size: | 23mm max. (approx.) |
| Dimension (Box): | 183 (L) x 61.3 (W) x 35.6 (H) mm
7.2″ (L) x 2.5″ (W) x 1.4″ (H) |
| Battery Type: | two 1.5V SUM-3 |
| Range Selection: | Manual |
| Power Consumption: | 10 mA (approx.) |
| Low Battery Indication: | red LED |
| Operating Temperature: | -10°C to 50°C |
| Operating Humidity: | less than 85% relative |
| Altitude: | up to 2000M |
| Storage Temperature: | -20°C to 60°C |
| Storage Humidity: | less than 75% relative |
| Weight: | 190g (battery included) |
| Accessories: | Carrying bag x 1
Users manual x 1 Batteries 1.5V x 2 Test leads |
