Sino HX601 Digital Pressure Gauge

The HX601 Digital Pressure Gauge is built with micropower components and proprietary software processing technology. Using Li-battery power, it can run continuously for 24 hours for two years. The data could be displayed more clearly with a 5-digit large crystal screen. Every HX601 has undergone high and low-temperature aging, ensuring more reliable precision. The product has been used in the power, chemical, petroleum, metallurgy, and metering industries, among others.

◆ Pressure range:：(-1-0)bar, (0-700)bar
(any range within this two ranges)
◆ Accuracy:：±0.05%F.S; 0.1%f.s, 0.2%f.s 0.5%f.s
◆ Display：5 digits with 14mm character height

Categories: Portable Inspection Gauges, Pressure Calibrator

Description

Technical specification
◆ Accuracy:±0.05%F.S,±0.1%F.S,±0.2%F.S, ,±0.5%F.S.
◆ Units kPa, Pa, psi, kgf/cm²,bar,mbar,mmH2O,mmHg,MPa .
◆ Temperature compensating range(0-50)℃
◆ Range: (-1-0)bar, (0-700)bar,(any range within this two range).
◆ Display: 5 digits with 14mm character height.
◆ Connection:M20*1.5, or 1/4”NPT male thread(or customized)
◆ Dimensions:Φ92.6mm×41mm.Weight:0.5kg.Height:133mm

Features
◆ Low Power Consumption: 1pc disposable 3.6Vdc Lithium battery.
◆ 5-digit big LCD with backlight function
◆ 9 Pressure Units selectable
◆ Zero point, full scale calibration function
◆ Adopting the special software treatment technology, it is unnecessary to preheat.
◆ RS232 Communication Port can communicate with the computer conveniently.
◆ Temperature compensating
◆ Overload alarm function
◆ % indication with bar graph scale for visual regerence
◆ Stainless steel bottom connection for robustness
◆ Equipped with rugged aluminum alloy cover; lighter weight
◆ CE&EX approved

Sino HX601 Digital Pressure Gauge
