MikroTest

Features:

Zinc die-cast housing that is heavy-duty.
Due to the manufacturing technique used by ElektroPhysik, the magnet has a long-lasting durability.
Range of measurement of up to 20 mm.
Because of the weight adjustment, it may be utilised in various situations, including horizontal, vertical, and above.
Curved surfaces can also be measured.
No need for batteries.

Specifications:

Property	Value
Range	6 S3: 0,2 mm – 3 mm 6 S5: 0,5 – 5 mm 6 S10: 2,5 – 10 mm 6 NiFe50: 0 µm – 50 µm
Application	6 S3; 6 S5; 6 S10 Enamel, plastic, rubber on steel. 6 NiFe50* Electroplated nickel on steel. Steel: ST 33 to ST 60
Tolerance	6 S3: ± 5 % – of reading 6 S5: ± 5 % – of reading 6 S10: ± 5 % – of reading 6 NiFe50: ± 2 µm 6 NiFe50: + 8 % – of reading
Minimum surface	6 S3: Ø 30 mm 6 S5: Ø 50 mm 6 S10: Ø 50 mm 6 NiFe50: Ø 20 mm
Minimum curvature radius	6 S3: 15 mm – convex 6 S3: 25 mm – concave 6 S5: 15 mm – convex 6 S5: 25 mm – concave 6 S10: 15 mm – convex 6 S10: 25 mm – concave 6 NiFe50: 10 mm – convex 6 NiFe50: 25 mm – concave
Minimum base thickness	6 S3: 1,0 mm 6 S5: 1,0 mm 6 S10: 2,0 mm 6 NiFe50: 0,5 mm
Ambient temperature	-20 °C – 100 °C
Dimensions and weight	Dimensions: Gauge 215 mm x 55 mm x 29 mm Plastic carrying case 235 mm x 185 mm x 46 mm Weight: Case incl. gauge approx. 560 g
