Mahr Metrology Precimar PLM 600-E
The precision length measuring machine PLM-E is a comparator according to Ernst Abbe with horizontal base bed (hard rock with high homogeneity and stiffness)
- Precision length measuring machine PLM 600-E
- Measuring range Outdoor measurement [mm] 0 to 600
- Measuring range Internal measurement [mm]
Description
| Precimar PLM 600-E | Art.-No. 5350700 | |
|---|---|
| Measuring range outdoor measurement [mm] | 0 to 600 |
| Table surface (A x B) mm | 150 X 300 |
| Measuring range internal measurement [mm] | 0.5 to 445 |
| Direct measuring range [mm] | 200 |
| Position deviation / MPE (L in mm) [μm] * | ≤ (0.07 + L/2000) |
| Length measurement deviation MPEE1 (L in mm) [μm] | ≤ (0.085 + L/1500) |
| Measuring forces [N] | 0 to 13.9 |
| Repeatability [μm] | ≤ 0.05 |
| Probing speed with joystick (max) | 8 mm/s |
| Device length [mm] | 1660 |
| Mass [kg] | 480 |
