Fungilab – Capillary Ubbelohde (ASTM & DIN)
Features
These FUNGILAB glass capillary viscometers allow to determine viscosities using ASTM and DIN testing methods. All capillary viscometers are supplied with the cali- bration certificate issued in accordance with the conditions of accreditation granted by a National Metrological Register which has assessed the measurement capability of the laboratory, the test uncertainty and its traceability to recognized international standards UKAS.
Ubbelohde Viscometers are used to determine kinematic viscosity of transparent Newtonian liquids. Sample volume: aprox. 15 ml. Precision: ±0.2%. *Fungilab offers many types of glass capillary viscometers that are not listed in our catalog. We can also manufacture glass capillary viscometers with customer-specified constants. Viscometers with special constants, added temps, and before/after data are available by special order. For further information contact Fungilab.
UBBELOHDE ASTM
(ASTM D445-446, ASTM D2515, ISO 3104-3105 and UNE 400313)
| CODE | DESCRIPTION | VISCOSITY RANGE | MATERIAL | CONSTANT K APPROX. | INCLUDED |
|---|---|---|---|---|---|
| CV003-001 | Ubbelohde ASTM size 0 | 0.3 – 1 cSt | Glass | 0.001 | Capillary Tube – Calibration Certificate |
| CV003-002 | Ubbelohde ASTM size 0C | 0.6 to 3 cSt | Glass | 0.003 | Capillary Tube – Calibration Certificate |
| CV003-003 | Ubbelohde ASTM size 0B | 1 to 5 cSt | Glass | 0.005 | Capillary Tube – Calibration Certificate |
| CV003-004 | Ubbelohde ASTM size 1 | 2 to 10 cSt | Glass | 0.01 | Capillary Tube – Calibration Certificate |
| CV003-005 | Ubbelohde ASTM size 1C | 6 to 30 cSt | Glass | 0.03 | Capillary Tube – Calibration Certificate |
| CV003-006 | Ubbelohde ASTM size 1B | 10 to 50 cSt | Glass | 0.05 | Capillary Tube – Calibration Certificate |
| CV003-007 | Ubbelohde ASTM size 2 | 20 to 100 cSt | Glass | 0.1 | Capillary Tube – Calibration Certificate |
| CV003-008 | Ubbelohde ASTM size 2C | 60 to 300 cSt | Glass | 0.3 | Capillary Tube – Calibration Certificate |
| CV003-009 | Ubbelohde ASTM size 2B | 100 to 500 cSt | Glass | 0.5 | Capillary Tube – Calibration Certificate |
| CV003-010 | Ubbelohde ASTM size 3 | 200 to 1.000 cSt | Glass | 1 | Capillary Tube – Calibration Certificate |
| CV003-011 | Ubbelohde ASTM size 3C | 600 to 3.000 cSt | Glass | 3 | Capillary Tube – Calibration Certificate |
| CV003-012 | Ubbelohde ASTM size 3B | 1.000 to 5.000 cSt | Glass | 5 | Capillary Tube – Calibration Certificate |
| CV003-013 | Ubbelohde ASTM size 4 | 2.000 to 10.000 cSt | Glass | 10 | Capillary Tube – Calibration Certificate |
| CV003-014 | Ubbelohde ASTM size 4C | 6.000 to 30.000 cSt | Glass | 30 | Capillary Tube – Calibration Certificate |
| CV003-015 | Ubbelohde ASTM size 4B | 10.000 to 50.000 cSt | Glass | 50 | Capillary Tube – Calibration Certificate |
| CV003-016 | Ubbelohde ASTM size 5 | 20.000 to 100.000 cSt | Glass | 100 | Capillary Tube – Calibration Certificate |
UBBELOHDE DIN
(DIN 51562 Part 1, ISO 3105 and UNE 400313)
| CODE | DESCRIPTION | VISCOSITY RANGE | MATERIAL | CONSTANT K APPROX. | INCLUDED |
|---|---|---|---|---|---|
| CV003-100 | Ubbelohde DIN size 0 | 0.35 to 1 cSt | Glass | 0.001 | Capillary Tube – Calibration Certificate |
| CV003-101 | Ubbelohde DIN size 0c | 0.7 to 3 cSt | Glass | 0.003 | Capillary Tube – Calibration Certificate |
| CV003-102 | Ubbelohde DIN size 0a | 1 to 5 cSt | Glass | 0.005 | Capillary Tube – Calibration Certificate |
| CV003-103 | Ubbelohde DIN size I | 2 to 10 cSt | Glass | 0.01 | Capillary Tube – Calibration Certificate |
| CV003-104 | Ubbelohde DIN size Ic | 6 to 30 cSt | Glass | 0.03 | Capillary Tube – Calibration Certificate |
| CV003-111 | Ubbelohde DIN size Ia | 10 to 50 cSt | Glass | 0.05 | Capillary Tube – Calibration Certificate |
| CV003-105 | Ubbelohde DIN size II | 20 to 100 cSt | Glass | 0.1 | Capillary Tube – Calibration Certificate |
| CV003-106 | Ubbelohde DIN size IIc | 60 to 300 cSt | Glass | 0.3 | Capillary Tube – Calibration Certificate |
| CV003-112 | Ubbelohde DIN size IIa | 100 to 500 cSt | Glass | 0.5 | Capillary Tube – Calibration Certificate |
| CV003-107 | Ubbelohde DIN size III | 200 to 1,000 cSt | Glass | 1 | Capillary Tube – Calibration Certificate |
| CV003-108 | Ubbelohde DIN size IIIc | 600 to 3,000 cSt | Glass | 3 | Capillary Tube – Calibration Certificate |
| CV003-113 | Ubbelohde DIN size IIIa | 1000 to 5,000 cSt | Glass | 5 | Capillary Tube – Calibration Certificate |
| CV003-109 | Ubbelohde DIN size IV | 2,000 to 10,000 cSt | Glass | 10 | Capillary Tube – Calibration Certificate |
| CV003-110 | Ubbelohde DIN size IVc | 6,000 to 30,000 cSt | Glass | 30 | Capillary Tube – Calibration Certificate |
| CV003-114 | Ubbelohde DIN size IVa | 10,000 to 50,000 cSt | Glass | 50 | Capillary Tube – Calibration Certificate |
